- Size: 2
- Place of Origin: CHINA
- Brand Name: qikai
- Model Number: 1.0mm-3.0mm
- Weight: 2.000 kg
More detailed products pls contact me.
Specification>>>
HDPE geomembrane specifications(USA GRI-GM17 Standards)
No. | Item | Value | ||||||
0.75mm | 1.00mm | 1.25mm | 1.50mm | 2.00mm | 2.50mm | 3.00mm | ||
1 | Density (g/cm3) | 0.939 | ||||||
2 | Yield strength (N/mm) | 11 | 15 | 18 | 22 | 29 | 37 | 44 |
Break strength (N/mm) | 20 | 27 | 33 | 40 | 53 | 67 | 80 | |
Yield elongation/% | 12 | |||||||
Break elongation/% | ≥450 | |||||||
3 | Tear resistance/N | 93 | 125 | 156 | 187 | 249 | 311 | 374 |
4 | Puncture resistance/N | 240 | 320 | 400 | 480 | 640 | 800 | 960 |
5 | Stress crack resistance/h | ≥1500 | ||||||
6 | Carbon black content/% | 2.0-3.0 | ||||||
Carbon black dispersion | Carbon black dispersion(only near spherical agglomerates) for 10 different views 9 in categories 1 or 2 and 1 in category 3 | |||||||
7 | Oxidative induction time/min | Standard OIT≥100 High pressure OIT≥400 | ||||||
8 | Oven aging at 85°C | |||||||
Standard OIT-% retained after 90days | 55 | |||||||
High pressure OIT-% retained after 90days | 80 | |||||||
9 | UV Resistance | |||||||
Standard OIT retained after 1600hrs | 50 | |||||||
High pressure OIT retained after 1600hrs | 50 | |||||||
10 | -70°C Low temperature impact brittle property | Pass | ||||||
11 | Permeability g•cm(cm2)•pa | ≤1.0× | ||||||
12 | Dimensional stability/% | ±2 |
Usage>>>
1.Prevent leakage disposal in waste burying field or waste water or waste dregs disposing field.
2. River bank, lake dam, mine remaining reservoir, tunnel, liquid storage pool(pit, mine).
3. Preventing leakage in subway, basement, tunnel, hole. Anti-salt leakage in roadbed and other groundsill.
4. The plane direction laying of dam, the vertical direction laying for groundsill, used in the construction fence and waste material field.
5. Used in groundsill of road, highway, railway and waterproof layer of swelling clay and wet collapsed loess.
